Neodymium Disc Magnet Zine Neodymium Magnets Rare Earth N35 from China manufacturer

Neodymium Disc Magnet Zine Neodymium Magnets Rare Earth N35

Price:	0.01~20.0 USD
Payment Terms:	T/T,L/C;paypal
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: Neodymium Disc Magnets D15X...

Production Capacity: 100 tons per month

Delivery Date: 15days

Shape: Bar

Composite: NdFeB Magnet

Means of Transport: Ocean,Air

Packing: Neutral packing

Application: Industrial Magnet

Type: Permanent

Brand Name: Xiong hai

Neodymium Disc Magnet.Zine Plated,super strong, high quality magnet . Can be magnetized thru thickess or diameter .It is used where a small size.

Sintered NdFeB magnets are the most powerful permanent magnetic materials commercially available, possessing high energy ranging from 30 MGOe to 50MGOe and wonderful coercive force. As the third generation of Rare Earth permanent magnets, NdFeB magnets are less brittle than SmCo. Sintered NdFeB has been widely used in high performance stepper, DC, servo, and linear motors, actuators, loudspeakers, headphones, instrumentation, switches, relays, magnetic imaging for medical and geophysical applications, holding systems, magnetic bearings, magnetic couplings, hard disk drives, etc..

Neodymium magnets are highly susceptible to corrosion. We offer a variety of coating and plating options to prevent corrosion and mechanical damage, such as Metallic Zinc, Nickel, Nickel+Nickel, Copper+Nickel, Nickel+Copper+Nickel, Gold, Organic Epoxy, Nickel+Epoxy coating.

The Surface Coatings of Neodymium Permanent Magnete Super Strong Magneti Neodimio Rare Earth Aimant Neodyme:

Surface
Coating
thickness(um)
Coating Color
SST
(hours)
PCT
(hours)
Nickel
Ni+Ni
Ni+Cu+Ni
10~20
Bright Silvery
24~72
24~72
Black Nickel
Ni+Cu+Ni
10~20
Bright Black
48~96
48
Cr3+Zinc
Zn
Cr-Zn
5~8
Bright Blue
Shining Color
16~48
36~72
\
Sn
Ni+Cu+Ni+Sn
10~25
Silver
36~72
48
Au
Ni+Cu+Ni+Au
10~25
Gold
12
48
Ag
Ni+Cu+Ni+Ag
10~25
Silver
12
48
Epoxy
Epoxy
Ni+Cu+Epoxy
Zn+Epoxy
10-20
15-30
15-25
Black / Grey
48
72~108
72~108

Passivation
\
1-3
Dark Grey
Temporary Protection
\
Phosphated
\
1-3
Dark Grey
Temporary Protection
\

Our neodymium disc magnets are mainly used in holding equipment. Some small disc magnets with lower energy are also used in auto speakers.

We can provide low energy neo material with competitive price for holding equipment or auto speakers. But our high energy like N50 or N52 is really powerful for high performance holding equipment.

You will find we are providing all lines of neo material with suitable price, we are expert to control the cost of neodymium magnets.

Counter sunk hole NdFeB magnet

1. Materials: Rare earth Neodymium-Iron-Boron, Permanent Sintered Ndfeb Magnets;

2. Certification: ISO9001:2008;

3. Magnetic properties:

a) High coercive force,

b) (BH)max from 33 to 53MGOe,

c) Max working temperature up to 230°C;

4. Grades: N33-N52,33M-48M,33H-48H,30SH-45SH,30UH-38UH, 30EH-35EH;

5. Shapes: Arc/Segment, or others;

6. Sizes: R x r x H x Degree, Customized;

7. Coatings: Ni, Zn, gold, copper, epoxy, chemical, parylene and so on;

Applications: sensors, motors, rotors, wind turbine,wind generators, loudspeakers, magnetic hooks, filters automobiles, Toys, micro-special electric machinery, audio equipments, electronic industry, auto industry, magnetic transmission gears and magnet therapy equipment, sorption, ads, teaching tools and other office automation, magnet toys, aero generators, magnetic toys, magnetic separators, magnetic bracelets, magnetic necklaces, copiers, synchrotrons, radiation sources, free electron lasers, agriculture, detection earthquake, and so on.

The Magnetic Properties of Neodymium Permanent Magnete Super Strong Magneti Neodimio Rare Earth Aimant Neodyme:

Magnetic Properties of Sintered NdFeB Magnets

Grade	Remanence		Coercivity Force		Intrinsic Coercive Force		Max. Energy Product		maximum Operating Temp.
	Br		Hcb		Hcj		( BH ) max
	mT	kGs	kA/m	kOe	kA/m	kOe	kJ/m3	MGOe
N35	1170-1220	11.7-12.2	≥868	≥10.9	≥955	≥12	263-287	33-36	80 ℃
N38	1220-1250	12.2-12.5	≥899	≥11.3	≥955	≥12	287-310	36-39	80 ℃
N40	1250-1280	12.5-12.8	≥907	≥11.4	≥955	≥12	302-326	38-41	80 ℃
N42	1280-1320	12.8-13.2	≥915	≥11.5	≥955	≥12	318-342	40-43	80 ℃
N45	1320-1380	13.2-13.8	≥923	≥11.6	≥955	≥12	342-366	43-46	80 ℃
N48	1380-1420	13.8-14.2	≥923	≥11.6	≥876	≥12	366-390	46-49	80 ℃
N50	1400-1450	14.0-14.5	≥796	≥10.0	≥876	≥11	382-406	48-51	60 ℃
N52	1430-1480	14.3-14.8	≥796	≥10.0	≥876	≥11	398-422	50-53	60 ℃
33M	1130-1170	11.3-11.7	≥836	≥10.5	≥1114	≥14	247-263	31-33	100 ℃
35M	1170-1220	11.7-12.2	≥868	≥10.9	≥1114	≥14	263-287	33-36	100 ℃
38M	1220-1250	12.2-12.5	≥899	≥11.3	≥1114	≥14	287-310	36-39	100 ℃
40M	1250-1280	12.5-12.8	≥923	≥11.6	≥1114	≥14	302-326	38-41	100 ℃
42M	1280-1320	12.8-13.2	≥955	≥12.0	≥1114	≥14	318-342	40-43	100 ℃
45M	1320-1380	13.2-13.8	≥995	≥12.5	≥1114	≥14	342-366	43-46	100 ℃
48M	1360-1430	13.6-14.3	≥1027	≥12.9	≥1114	≥14	366-390	46-49	100 ℃
50M	1400-1450	14.0-14.5	≥1033	≥13.0	≥1114	≥14	382-406	48-51	100 ℃
33H	1130-1170	11.3-11.7	≥836	≥10.5	≥1353	≥17	247-271	31-34	120 ℃
35H	1170-1220	11.7-12.2	≥868	≥10.9	≥1353	≥17	263-287	33-36	120 ℃
38H	1220-1250	12.2-12.5	≥899	≥11.3	≥1353	≥17	287-310	36-39	120 ℃
40H	1250-1280	12.5-12.8	≥923	≥11.6	≥1353	≥17	302-326	38-41	120 ℃
42H	1280-1320	12.8-13.2	≥955	≥12.0	≥1353	≥17	318-342	40-43	120 ℃
45H	1300-1360	13-13.6	≥963	≥12.1	≥1353	≥17	326-358	43-46	120 ℃
48H	1370-1430	13.7-14.3	≥995	≥12.5	≥1353	≥17	366-390	46-49	120 ℃
33SH	1130-1170	11.3-11.7	≥844	≥10.6	≥1592	≥20	247-271	31-34	150 ℃
35SH	1170-1220	11.7-12.2	≥876	≥11.0	≥1592	≥20	263-287	33-36	150 ℃
38SH	1220-1250	12.2-12.5	≥907	≥11.4	≥1592	≥20	287-310	36-39	150 ℃
40SH	1240-1280	12.5-12.8	≥939	≥11.8	≥1592	≥20	302-326	38-41	150 ℃
42SH	1280-1320	12.8-13.2	≥987	≥12.4	≥1592	≥20	318-342	40-43	150 ℃
45SH	1320-1380	13.2-13.8	≥1003	≥12.6	≥1592	≥20	342-366	43-46	150 ℃
28UH	1020-1080	10.2-10.8	≥764	≥9.6	≥1990	≥25	207-231	26-29	180 ℃
30UH	1080-1130	10.8-11.3	≥812	≥10.2	≥1990	≥25	223-247	28-31	180 ℃
33UH	1130-1170	11.3-11.7	≥852	≥10.7	≥1990	≥25	247-271	31-34	180 ℃
35UH	1180-1220	11.8-12.2	≥860	≥10.8	≥1990	≥25	263-287	33-36	180 ℃
38UH	1220-1250	12.2-12.5	≥876	≥11.0	≥1990	≥25	287-310	36-39	180 ℃
40UH	1240-1280	12.5-12.8	≥899	≥11.3	≥1990	≥25	302-326	38-41	180 ℃
42UH	1280-1320	12.8-13.2	≥899	≥11.3	≥1990	≥25	318-342	40-43	180 ℃
28EH	1040-1090	10.4-10.9	≥780	≥9.8	≥2388	≥30	207-231	26-29	200 ℃
30EH	1080-1130	10.8-11.3	≥812	≥10.2	≥2388	≥30	223-247	28-31	200 ℃
33EH	1130-1170	11.3-11.7	≥836	≥10.5	≥2388	≥30	247-271	31-34	200 ℃
35EH	1170-1220	11.7-12.2	≥876	≥11.0	≥2388	≥30	263-287	33-36	200 ℃
38EH	1220-1250	12.2-12.5	≥899	≥11.3	≥2388	≥30	287-310	36-39	200 ℃
40EH	1250-1280	12.5-12.8	≥899	≥11.3	≥2388	≥30	287-310	38-41	200 ℃
28AH	1040-1080	10.4-10.8	≥787	≥9.9	≥2624	≥33	207-231	26-29	230 ℃
30AH	1080-1130	10.8-11.3	≥819	≥10.3	≥2624	≥33	223-247	28-31	230 ℃
33AH	1130-1170	11.3-11.7	≥843	≥10.6	≥2624	≥33	247-271	31-34	230 ℃
35AH	1170-1220	11.7-12.2	≥876	≥11.0	≥2624	≥33	263-287	33-36	230 ℃

Pictures of Neodymium rod magnet has been presented above, want more similar products, please click Neodymium disc magnet,ndfeb cylinder magnet,neodymium rod magnet.

Neodymium Disc Magnets Disc Zine plated magnets Rare Earth N33,N35,N38,N40,N42,N45,N48,N50,N52, (M, H, SH, EH, UH,AH )
